Step-by-step instructions to fix, replace, or upgrade different parts of the ASI system.

• 05:38



  How to Program Your W&H Handpieces [66-4048]

  This video provides step-by-step instructions for programming all handpieces on the W&H controller integrated into your ASI Delivery System. Learn how to link each handpiece to the motor controller so that your system recognizes it and is ready for use. Intended for dental practitioners and clinical staff. Note: ASI systems with integrated W&H controllers arrive pre-programmed. Reprogramming is only needed when handpieces are added to or removed from the cart, or if the controller has been factory reset.

• 01:57



  Replace the Master Air Regulator - Units Made Before August 2016 [66-4013]

  "A step-by-step giude on how to replace the Master Air Regulator on units made before August 2016, located on the air tanks, inside the ASI system. Click Here to order Master Air Regulator parts. Copyright © ASI Medical. All rights reserved."

• 02:15



  Replace the Master Air Regulator - Units Made After August 2016 [66-4012]

  "A step-by-step giude on how to replace the Master Air Regulator on units made after August 2016, located on the air tanks, inside the ASI system. Click Here to order the Master Air Regulator parts. Copyright © ASI Medical. All rights reserved."

• 02:31



  Replace the Control Block Diaphragm Pucks [66-4007]

  "A step-by-step guide on replacing the diaphragm pucks in the control block. This is for models made AFTER October 24, 2006. Copyright © ASI Medical. All rights reserved."

• 02:32



  Replace the Control Block Diaphragm [66-4006]

  "A step-by-step guide on replacing the diaphragm in the control block. This guide is for systems made BEFORE October 23, 2006. Click Here to order a control block diaphragm. Copyright © ASI Medical. All rights reserved."

• 01:32



  Replace the Check Valve on the ASI Air Compressor [66-4010]

  A step-by-step guide on how to replace the check valve poppet in the ASI air compressor.

• 01:11



  Replace the Air/Water Syringe Buttons [66-4000]

  "A step-by-step guide on how to replace the button/cartridge on your Air/Water syringe. Click Here to order the Air/Water Button Cartridge Replacement. Copyright © ASI Medical. All rights reserved."

• 02:04



  Removing the Root ZX II Apex Locator for repair [66-4024]

  "This video demonstrates how to remove the Root ZX II Apex Locator from the ASI Dental Delivery system when sending in for repair. Copyright © ASI Medical. All rights reserved."

• 01:38



  Removing/Replacing the Capacitor on the Compressor [66-4019]

  "This video demonstrates how to remove the faulty capacitor and replace with a new capacitor. This can be done on the same way on both the compressor pump or the vacuum pump, as the capacitor is the same for both. Copyright © ASI Medical. All rights reserved."

• 02:00



  Removing Lever from Auto Holder

  "This video demonstrates how to remove and replace the auto lock lever on the side of the auto holder. Copyright © ASI Medical. All rights reserved."

• 00:21



  Removing and Replacing Window Overlay [66-4017]

  "This video demonstrates how to remove and replace the window overlay on the front of the ASI dental delivery system. Copyright © ASI Medical. All rights reserved."

• 00:57



  Removing and Replacing Fiber Optic Pin Adapter [66-4033]

  "This video demonstrates how to Remove and replace the fiber optic pin adapter on the ASI Fiber Optic tubing. Copyright © ASI Medical. All rights reserved."
